Product Overview
The M Tara Fixed LED Stroboscope is engineered for continuous industrial inspection where accurate monitoring of fast-moving machine components is essential. By synchronizing the LED flash frequency with machine speed, operators can easily inspect print defects, web tracking, roller performance, and registration accuracy while production remains uninterrupted.
Equipped with high-brightness SMD Super Flex LEDs, the stroboscope provides consistent illumination with a LED colour temperature of 5000 K and a service life exceeding 50,000 hours, significantly reducing maintenance requirements. The unit operates on a 220V AC power supply with an adjustable flash rate of 10–75 Hz, making it suitable for machine speeds up to 600 metres per minute. Available in multiple coverage sizes, it can be installed across a wide range of industrial printing and converting machines.
Technical Specification
|
Specification |
Details |
|
Product |
M Tara Fixed LED Stroboscope |
|
Strobe Type |
LED Strobe |
|
Lighting Type |
LED |
|
Mounting |
Fixed Mount |
|
Display Type |
LED |
|
Usage/Application |
Industrial |
|
Application |
Printing & Converting Inspection |
|
Power Supply |
220V AC |
|
LED Temperature |
5000 K |
|
LED Type |
SMD Super Flex |
|
LED Life |
More than 50,000 Hours |
|
Operating Frequency (Flash Rate) |
10–75 Hz |
|
Maximum Machine Speed |
Up to 600 metres/minute |
|
Available Sizes |
300 mm, 600 mm, 900 mm, 1100 mm, 1200 mm |
|
Industry Use |
Gravure Printing, Flexographic Printing, Offset Printing, Laminating, Coating, Flexible Packaging |
Key Features
- High-intensity LED strobe for continuous inspection.
- Fixed mounting for permanent machine installation.
- SMD Super Flex LED technology.
- LED life of more than 50,000 hours.
- Adjustable flash frequency from 10–75 Hz.
- Suitable for machine speeds up to 600 metres/minute.
- Bright 5000 K LED illumination.
- Low maintenance and energy-efficient operation.
- Ideal for continuous industrial use.
